1/4" Dia, 4 Flute, Router - 72971
SERIES: 25
Series 25 - CFRP Compression Router
1/4" Dia, 1" LOC, 2-1/2" OAL, 1/4" Shank Dia, 4 Flute, 30 Degree Helix, Di-NAMITE (Diamond) Coated, Series 25, Series 25 - CFRP Compression Router - 72971
Feature & Benefits
Left Hand Helix
Right Hand Helix
Series Description | Series 25 - CFRP Compression Router |
---|---|
High Performance | Yes |
End Configuration | Square End |
Tool Length | Long |
Unit (inch/mm) | inch |
Number of Flutes | 4 |
Primary Workpiece Material | (N) Non-Ferrous Materials |
Cutting Diameter (DC) (Decimal Inch) | 0.2500 |
Cutting Diameter (DC) (Fractional Inch) | 1/4 |
Cutting Diameter (DC) (mm) | 6.35 |
Shank Diameter (DCON) (Decimal Inch) | 0.2500 |
Shank Diameter (DCON) (mm) | 6.35 |
Length of Cut (APMX) (Decimal Inch) | 1.0000 |
Length of Cut (APMX) (Fractional Inch) | 1 |
Length of Cut (APMX) (mm) | 25.40 |
Overall Length (LF) (Decimal Inch) | 2.5000 |
Overall Length (LF) (Fractional Inch) | 2-1/2 |
Overall Length (LF) (mm) | 63.50 |
Shank Length (LS) (Decimal Inch) | 1.5000 |
Shank Length (LS) (Fractional Inch) | 1-1/2 |
Split Length (SPTL) (Fractional Inch) | 11/64 |
Cutting Diameter (DC) Tolerance (Decimal Inch) | +0.0000/-0.0030 |
Cutting Diameter (DC) Tolerance (mm) | +0.000/-0.080 |
Shank Diameter (DCON) Tolerance (ISO) | h6 |
Shank Type | Straight |
Coolant Option | External Coolant |
Additional Geometry | Right Hand Cut Direction (RHC) |
Rake Angle | Positive |
Helix Angle | Right Spiral |
Helix Angle (Degree) | 30 |
Variable Helix | No |
Center Cutting | Yes |
Chip Breaker | No |
KPT Micro Crossover (Old Material Number) | 8522409 |
KPT Micro Crossover (Part Number) | 1890-2500V1000 |
Shipping Weight | 0.0670 |
Series | 25 |
Weldon Flat | No |
US Stock | 10 |
Shank Length (LS) (mm) | 38.10 |
Shank Diameter (DCON) (Fractional Inch) | 1/4 |
Coating Description | Diamond (Di-NAMITE) |
